S&S Cycle Cam Chest Kit with Plate — Chain Drive — Water Cooled — 540 Cam — Chrome Pushrods — M8

540 cam is designed for acceleration torque in 124" and larger engines.

Enhances torque output in 4.25" big bore kits.

Kit Includes:

• Quickee Pushrod Kit with Chrome Covers

• Tappet Cuffs Lifter Guide

• Oil Pump with Cam Plate

• Hydraulic Tappet Set

• 540C Camshaft Kit

• Spring Kit

• Cam Chain Tensioner.

• Oil Pump/Cam Plate:
• Precision machined from billet aluminum
• Blue anodized finish
• Passage plugs removable for servicing
• Independant scavenge sections for flywheel cavity and cam chest
• Debris screens in both pickups
• Magnet in cam chest to help stop debris from entering oil pump
• Increased flow capacity on both feed and scavenge side
• Adjustable pressure relief vale is adjustable with unit installed in engine
• Includes S&S high performance cam chain tensioner
• Pushrods:
• Quickee pushrods
• Tappets:
• S&S precision tappets
• Tappet Cuffs:
• Hard anodized black coating
• Billet aluminum construction
• Stronger than stock material eliminates distortion
• Improves tappet stability in high lift and high rpm situations
• Cam:
• Includes all gaskets, bearings and hardware for installation
• Made in the USA

Grind

540C

Intake Open

17.7° Front, 14.9° Rear

Units

Kit

Exhaust Lift at TDC

0.262" Front, 0.216" Rear

Intake Lift at TDC

0.175" Front, 0.161" Rear

Model

540 Big Bore Torque

Exhaust Duration

235.1° Front, 244.6° Rear

Exhaust Lobe Centerline

83.6° Front, 95.4° Rear

Exhaust Lift

0.540"

Intake Close

30.6° Front, 28.7° Rear

Application

Water Cooled

Exhaust Open

21.2° Front, 37.7° Rear

Features

Chrome Pushrod Tubes

Intake Duration

228.3° Front, 223.6° Rear

Intake Lift

0.540"

Intake Lobe Centerline

96.4° Front, 96.9° Rear

Riding Style

Street

Exhaust Close

33.9° Front, 26.9° Rear

Type

Chain

Shipping weight

11.95 lb

Package size

17.8 × 11.5 × 5.1 in

Country of origin

USA

Salto part #

0925-1364

S&S Cycle part #

310-1116A

In stock. Ships in 2–4 business days by ground.

Ground shipping is $14.95, free on orders over $150. Stock is checked again before your card is charged.

California: this part can’t ship to a California address.

Is it in stock?

Yes — it’s in stock right now. We check again the moment you order, before anything is charged.

How fast will it get to me?

Usually 2–4 business days by ground.

Will it fit my machine?

It’s listed for the models in the Fitment section above. Not sure about your trim or year? Call the counter at 801-361-3010 and we’ll check it with you.

Is this genuine S&S Cycle?

Yes. It’s new and genuine, straight from Salto — S&S Cycle part #310-1116A.
