Feuling Parts Valve Spring Kit — For 7.00 mm Valve Stem — 88"/96"/103" Twin Cam | XL | XR1200
- Machined from premium-grade hi-tensile chrome silicon single-conical ovate wire
- Shot-peened with specially processed thermal heat treat and super NexTex® finish for fatigue life needed to exceed high demands of V-Twin engines
- Use a much smaller and lighter weight retainer to reduce valve weight and create quicker rev and smoother motion
- Direct bolt-in replacement up to 0.650" cam lift; no machining or rocker box clearancing required
- Kits include: Endurance BeeHive® valve springs, lightweight 7° super Titanium heat-treated retainers, machined spring seats, seat shims, valve locks and a set of premium Viton® valve seals equipped with spring-loaded valve stem wiper system
$379.95
In stock. Ships in 2–4 business days · free shipping over $150.
View cart & check out →
Questions? Call the shop: 801-361-3010
Real shop · real humans · 1231 N 1300 W Ste A, Centerville, UT 84014
Description & features17 features
Not for RH Sportster.
- Machined from premium-grade hi-tensile chrome silicon single-conical ovate wire
- Shot-peened with specially processed thermal heat treat and super NexTex® finish for fatigue life needed to exceed high demands of V-Twin engines
- Use a much smaller and lighter weight retainer to reduce valve weight and create quicker rev and smoother motion
- Direct bolt-in replacement up to 0.650" cam lift; no machining or rocker box clearancing required
- Kits include: Endurance BeeHive® valve springs, lightweight 7° super Titanium heat-treated retainers, machined spring seats, seat shims, valve locks and a set of premium Viton® valve seals equipped with spring-loaded valve stem wiper system
- Made in the USA
- Seat lb / installed height:
- 198 lb @ 1.685" (0.535" lift)
- 194 lb @ 1.703" (0.553" lift)
- 190 lb @ 1.724" (0.574" lift)
- 187 lb @ 1.754" (0.604" lift)
- 185 lb @ 1.780" (0.630" lift)
- 160 lb @ 1.800" (0.650" lift)
- 375 lb @ 1.150" Open Height
- Coil Bind @ 1.100"
- Must be installed at the correct open height, matching max lift to the open height spec of the valve springs.
- Feuling® BeeHive® valve spring kits are direct replacement with no machining or rocker box clearance required up to 0.574" lift for '98-'04 Big Twin and '86-'03 XL and up to 0.650" lift for '05-'17 Twin Cam. Larger camshafts require valve guide machining for seal to retainer clearance.
Specifications11 specs
- Units
- Kit
- Model
- Endurance Beehive
- Material
- Chrome-Silicon
- Style
- Ovate Wire Beehive
- Riding Style
- Street
- Application
- Exhaust, Intake
- Collar Material
- Titanium
- Type
- Valve
- Shipping weight
- 1.4 lb
- Package size
- 6.1 × 4.9 × 3.3 in
- Country of origin
- USA
Fitment144 models · Harley-Davidson
Harley-Davidson144 models
- 1200 Custom EFI XLC2004–2006
- 1200 Low EFI XLL2006
- 1200 Roadster EFI XLR2006
- 1200 XLCP2011–2017
- 15th Anniversary Fat Boy FLSTF2005
- 883 Custom EFI XLC2004–2006
- 883 EFI XL2009
- 883 Low EFI XLL2006
- 883 Roadster EFI XLR2005–2006
- 883 Roadster XLR2007
- Electra Glide Police FLHTPI2005–2016
- Electra Glide Police FLHTP2005–2006
- Electra Glide Ultra Classic FLHTCU2005–2006
- Electra Glide Ultra Classic Low FLHTCUL2014
- Fat Boy Lo FLSTFB2009
- FLD Switchback2012–2016
- FLHR Road King2005–2016
- FLHRC Road King Classic2007–2013
- FLHRCI Road King Classic2005–2006
- FLHRI Road King2005–2006
- FLHRS Road King Custom2005–2007
- FLHRSE3 Screamin Eagle Road King2007
- FLHRSE4 Screamin Eagle Road King2008
- FLHRSE5 CVO Road King2013
- FLHRSE6 CVO Road King2014
- FLHRSI Road King Custom2005–2006
- FLHT Electra Glide Standard2005–2009
- FLHTC Electra Glide Classic2005–2013
- FLHTCI Electra Glide Classic2005–2006
- FLHTCSE2 Screamin Eagle Electra Glide 22005
- FLHTCU Electra Glide Ultra Classic2007–2016
- FLHTCUI Electra Glide Ultra Classic2005–2006
- FLHTCUL Electra Glide Ultra Classic Low2015–2016
- FLHTCUSE Screamin Eagle Ultra Classic Electra Glide2006
- FLHTCUSE2 Screamin Eagle Ultra Classic Electra Glide2007
- FLHTCUSE3 Screamin Eagle Ultra Classic Electra Glide2008
- FLHTCUSE4 CVO Ultra Classic Electra Glide2009
- FLHTCUSE5 CVO Ultra Classic Electra Glide2010
- FLHTCUSE6 CVO Ultra Classic Electra Glide2011
- FLHTCUSE7 CVO Ultra Classic Electra Glide2012
- FLHTCUSE8 CVO Ultra Classic Electra Glide2013
- FLHTI Electra Glide Standard2005–2006
- FLHTK Ultra Limited2010–2016
- FLHTKL Ultra Limited Low2015–2016
- FLHTKSE CVO Limited2014–2016
- FLHX Street Glide2006–2016
- FLHXI Street Glide2006
- FLHXS Street Glide Special2014–2016
- FLHXSE CVO Street Glide2010, 2015–2016
- FLHXSE2 CVO Street Glide2011
- FLHXSE3 CVO Street Glide2012
- FLS Softail Slim2012–2017
- FLSS Softail Slim S2016–2017
- FLST Heritage Softail2006
- FLSTC Heritage Softail Classic2005–2017
- FLSTCI Heritage Softail Classic2005–2006
- FLSTF Fat Boy2005–2017
- FLSTFB Fat Boy Lo2010–2017
- FLSTFBS Fat Boy S2016–2017
- FLSTFI Fat Boy2005–2006
- FLSTFSE Screamin Eagle Fat Boy2005–2006
- FLSTFSE2 Screamin Eagle Fat Boy2006
- FLSTI Heritage Softail2006
- FLSTN Softail Deluxe2005–2017
- FLSTNI Softail Deluxe2005–2006
- FLSTNSE CVO Softail Deluxe2014–2015
- FLSTSB Cross Bones2008–2011
- FLSTSC Softail Springer Classic2005–2007
- FLSTSCI Softail Springer Classic2005–2006
- FLSTSE CVO Softail Convertible2010
- FLSTSE2 CVO Softail Convertible2011
- FLSTSE3 CVO Softail Convertible2012
- FLTR Road Glide2005–2010, 2016
- FLTRI Road Glide2005–2006
- FLTRSE3 CVO Road Glide2009
- FLTRU Road Glide Ultra2011–2013, 2016
- FLTRUSE CVO Road Glide Ultra2011, 2015–2016
- FLTRX Road Glide2015–2016
- FLTRX Road Glide Custom2010–2013
- FLTRXS Road Glide Special2015–2016
- FLTRXSE CVO Road Glide Custom2012
- FLTRXSE2 CVO Road Glide Custom2013
- FXCW Rocker2008–2009
- FXCWC Rocker C2008–2011
- FXD Dyna Super Glide2005–2010
- FXDB Street Bob2006–2017
- FXDBI Street Bob2006
- FXDC Super Glide Custom2005, 2007–2014
- FXDCI Super Glide Custom2005–2006
- FXDF Fat Bob2008–2017
- FXDFSE CVO Dyna Fat Bob2009
- FXDFSE2 CVO Dyna Fat Bob2010
- FXDI Dyna Super Glide2005–2006
- FXDI35 Dyna 35th Anniversary Super Glide2006
- FXDL Dyna Low Rider2005–2009, 2014–2017
- FXDLI Dyna Low Rider2005–2006
- FXDLS Low Rider S2016–2017
- FXDSE Screamin Eagle Dyna2007
- FXDSE2 Screamin Eagle Dyna2008
- FXDWG Dyna Wide Glide2005–2008, 2010–2017
- FXDWGI Dyna Wide Glide2005–2006
- FXDX Dyna Super Glide Sport2005
- FXDXI Dyna Super Glide Sport2005
- FXS Blackline2011–2013
- FXSB Breakout2013–2017
- FXSBSE CVO Breakout2013–2014
- FXSE CVO Pro Street Breakout2016–2017
- FXST Softail Standard2005–2009
- FXSTB Night Train2005–2009
- FXSTBI Night Train2005–2006
- FXSTC Softail Custom2007–2010
- FXSTD Softail Deuce2005–2007
- FXSTDI Softail Deuce2005–2006
- FXSTI Softail Standard2005–2006
- FXSTS Springer Softail2005–2006
- FXSTSI Springer Softail2005–2006
- FXSTSSE Screamin Eagle Softail Springer2007
- FXSTSSE2 Screamin Eagle Softail Springer2008
- FXSTSSE3 CVO Softail Springer2009
- Road King Police FLHP2007, 2009–2016
- Softail Rocker FXCW2010
- Softail Standard EFI FXSTI2010–2012
- Sportster 1200 X XR2009
- Sportster 1200 XR2011–2012
- XL1200C Sportster 1200 Custom2004–2019
- XL1200CX Roadster2016–2020
- XL1200L Sportster 1200 Low2006–2011
- XL1200N Sportster 1200 Nightster2007–2012
- XL1200NS Iron 12002018–2021
- XL1200R Sportster 1200 Roadster2004–2009
- XL1200T SuperLow 1200T2014–2017
- XL1200V Seventy-Two2012–2016
- XL1200X Forty-Eight2010–2022
- XL1200XS Forty-Eight Special2018–2019
- XL50 50th Anniversary Sportster2007
- XL883 Sportster2004–2008
- XL883C Sportster 883 Custom2004–2009
- XL883L Sportster 883 Low2005–2010
- XL883L SuperLow2011–2019
- XL883N Iron 8832009–2022
- XL883R Sportster 883 Roadster2005–2007
- XLH8832004
- XR12002009–2010
- XR1200X2010–2012
Fitment comes from the distributor’s catalog. Double-check your year, model and trim before you order — or call the counter at 801-361-3010 and we’ll check it with you.
Part numbers
- Salto part #
- 0926-0852
- Feuling Parts part #
- 1105
Shipping
In stock at a distributor warehouse. Ships in 2–4 business days by ground.
Ground shipping is $14.95, free on orders over $150. Stock is re-checked with the warehouse before your card is charged.
Questions4 answers
- Is it in stock?
- Yes — the distributor shows it on a shelf at a regional warehouse right now. We check again the moment you order, before anything is charged.
- How fast will it get to me?
- Usually 2–4 business days by ground.
- Will it fit my machine?
- The distributor lists it for the models in the Fitment section above. Not sure about your trim or year? Call the counter at 801-361-3010 and we’ll check it with you.
- Is this genuine Feuling Parts?
- Yes. It ships new from the same distributors the big online stores buy from — Feuling Parts part #1105.
