Feuling Parts Valve Spring Kit — Endurance Beehive with TI Retainers — TC with SE Heads

Fits Twin Cam Screamin' Eagle Heads with 5/16" valve stems with standard keeper grooves and .530" diameter valve guides.

Includes:

• Endurance Beehive Springs

• Titanium Retainers

• Spring Seats

• Seat Shims

• Valve Locks

• Viton Valve Seals.

• FEULING® BEEHIVE® valve springs use a much smaller and lighter weight retainer which drastically reduces the valve weight creating a much quicker revving and smoother motion than comparable dual valve springs
• FEULING® endurance springs are a direct bolt-in replacement (Up to 650 cam lift and doesn't require machining or rocker box clearancing)
• Eliminates valve spring separation, maximizes stability, reduces valve-train noise and harmonics
• FEULING® BEEHIVE® valve springs must be installed at the correct open height, matching max lift to the open height spec of the valve springs
• Machined from a premium grade Hi-tensile chrome silicon single conical ovate wire, shot-peened with a specially processed thermal heat treatment and super NexTex finish
• Kit includes FEULING® ENDURACE BEEHIVE® valve springs, lightweight 7° Titanium heat treated retainers, machined spring seats, seat shims, valve locks and a set of premium Viton® valve seals equipped with a spring loaded valve stem wiper system
• Made in the USA
• Seat lb / Installed Height :
• 198 lb @ 1.685 (0.535 Lift)
• 194 lb @ 1.703 (0.553 Lift)
• 190 lb @ 1.724 (0.574 Lift)
• 187 lb @ 1.754 (0.604 Lift)
• 185 lb @ 1.780 (0.630 Lift)
• 160 lb @ 1.800 (0.650 Lift)
• 375 lb @ 1.150 OPEN HEIGHT
• Coil Bind @ 1.100

Color/Finish

NexTex®

Material

Chrome-Silicon

Spring Lift

0,650", 0.650"

Application

Exhaust, Intake

Stem Diameter

7.056 mm

Collar Material

Titanium

Riding Style

Street

Units

Kit

Style

Ovate Wire Beehive

Type

Valve

Model

Endurance Beehive

Shipping weight

1.4 lb

Package size

6 × 4.9 × 3.6 in

Country of origin

USA

Salto part #

0926-1466

Feuling Parts part #

1101

In stock at a distributor warehouse. Ships in 2–4 business days by ground.

Ground shipping is $14.95, free on orders over $150. Stock is re-checked with the warehouse before your card is charged.

Is it in stock?

Yes — the distributor shows it on a shelf at a regional warehouse right now. We check again the moment you order, before anything is charged.

How fast will it get to me?

Usually 2–4 business days by ground.

Will it fit my machine?

The distributor doesn’t publish a vehicle fitment list for this part. Call the counter at 801-361-3010 with your year, make and model and we’ll check it with you before you order.

Is this genuine Feuling Parts?

Yes. It ships new from the same distributors the big online stores buy from — Feuling Parts part #1101.
