Kibblewhite Engine Valve Kit — 0.610" Lift — XL1200 '04-'22

Kibblewhite · #0926-3216 · Top End / Engine

Kits include KPMI® or equivalent valve spring kit, a full set of Black Diamond™stainless steel standard size valves and are black nitride coated, H.T. (Heat Treated) steel valve keepers and valve stem seals (where applicable) for engine applications listed
Black Diamond™ valves are one piece forged stainless steel that are fortified by a special German process to improve wear properties and reduce friction
White Diamond® valves are CNC machined from one-piece forging of either EV8 stainless steel or Inconel-751 and are hard chromed with 360° anode to produce a hard chrome finish
Compatible with leaded and unleaded fuels
Sold as complete kit for one engine

$337.54

In stock. Ships in 2–4 business days · free shipping over $150.

Questions? Call the shop: 801-361-3010

Real shop · real humans · 1231 N 1300 W Ste A, Centerville, UT 84014

Description & features6 features

Kit Includes:

• 2x Intake Valves

• 2x Exhaust Valves

• 4x Intake and Exhaust Retainers

• 4x Pairs of Intake and Exhaust Keepers

• 4x Intake and Exhaust Valve Springs

• 4x Intake and Exhaust Base Washers

• 4x Intake and Exhaust Red Vinton® Seals

Kits include KPMI® or equivalent valve spring kit, a full set of Black Diamond™stainless steel standard size valves and are black nitride coated, H.T. (Heat Treated) steel valve keepers and valve stem seals (where applicable) for engine applications listed
Black Diamond™ valves are one piece forged stainless steel that are fortified by a special German process to improve wear properties and reduce friction
White Diamond® valves are CNC machined from one-piece forging of either EV8 stainless steel or Inconel-751 and are hard chromed with 360° anode to produce a hard chrome finish
Compatible with leaded and unleaded fuels
Sold as complete kit for one engine
Made in the USA

Specifications16 specs

Spring Lift: 0.610", 0,610"
Application: Intake, Exhaust
Spring Seat Pressure: 175 lb
Stem Diameter: Intake 7.00 mm, Exhaust 7.00 mm, Intake 0.2760" Exhaust 0.2755"
Collar Material: H.T. Steel
Spring Open Pressure: 400 lb
Tulip Angle: Intake 28°, Exhaust 34°
Units: Kit
Length: Intake 5.525", Exhaust 4.610"
Riding Style: Street
Head Diameter: Intake 1.805", Exhaust 1.575", Intake 45.85 mm, Exhaust 40.00 mm
Material: Black Diamond™ Stainless
Valve Seat Height: 1.860"
Shipping weight: 1.9 lb
Package size: 8 × 8 × 2.3 in
Country of origin: USA

Fitment30 models · Harley-Davidson

Harley-Davidson30 models

1200 Custom EFI XLC2004–2006
1200 Low EFI XLL2006
1200 Roadster EFI XLR2006
1200 XLCP2011–2017
883 Custom EFI XLC2004–2006
883 EFI XL2009
883 Low EFI XLL2006
883 Roadster EFI XLR2005–2006
883 Roadster XLR2007
Sportster 1200 X XR2009
Sportster 1200 XR2011–2012
XL1200C Sportster 1200 Custom2004–2019
XL1200CX Roadster2016–2020
XL1200L Sportster 1200 Low2006–2011
XL1200N Sportster 1200 Nightster2007–2012
XL1200NS Iron 12002018–2021
XL1200R Sportster 1200 Roadster2004–2009
XL1200T SuperLow 1200T2014–2017
XL1200V Seventy-Two2012–2016
XL1200X Forty-Eight2010–2022
XL1200XS Forty-Eight Special2018–2019
XL50 50th Anniversary Sportster2007
XL883 Sportster2004–2008
XL883C Sportster 883 Custom2004–2009
XL883L Sportster 883 Low2005–2010
XL883L SuperLow2011–2019
XL883N Iron 8832009–2021
XL883R Sportster 883 Roadster2005–2007
XR12002010
XR1200X2010–2012

Fitment comes from the distributor’s catalog. Double-check your year, model and trim before you order — or call the counter at 801-361-3010 and we’ll check it with you.

Part numbers

Salto part #: 0926-3216
Kibblewhite part #: 20-22950
