Legend Suspension REVO ARC Piggyback Shocks — 13" — Standard — Clear — '84-'00 FXR

In warehouse stock

Legend Suspension REVO ARC Piggyback Shocks — 13" — Standard — Clear — '84-'00 FXR

Legend Suspension · #1310-1946 · Rear Suspension / Suspension & Frame

Available in Black, Gold and Clear Type III hard coat anodize
Legend's touring specific coil spring rates provide superior ride comfort, improved performance, and increased resistance to bottoming for all day comfort
Adjusts by hand, no tools needed
Available in 13" and 14", standard or heavy-duty applications
Easy installation and alignment, provided by spherical bearings on both top and bottom mounting points

$1499.95

In stock. Ships in 2–4 business days · free shipping over $150.

Questions? Call the shop: 801-361-3010

Real shop · real humans · 1231 N 1300 W Ste A, Centerville, UT 84014

Description & features15 features

FXR MODELS: Heavy Duty application is recommended for 500 lb+ rider and passenger total weight. Also consider Heavy Duty if the majority of your riding is 2-UP, stunt riding, or aggressive riding style.

Available in Black, Gold and Clear Type III hard coat anodize
Legend's touring specific coil spring rates provide superior ride comfort, improved performance, and increased resistance to bottoming for all day comfort
Adjusts by hand, no tools needed
Available in 13" and 14", standard or heavy-duty applications
Easy installation and alignment, provided by spherical bearings on both top and bottom mounting points
35 mm monotube construction
Deflective disc valve stacks
Balanced/Matched piston and base-valve design specific for motorcycle applications
Low friction sealing system and sliding bearings for improved performance and feel
Features independent compression and rebound damping adjusters that are specifically designed to make fast, precise, and repeatable changes to ride comfort and performance with a simple turn of a knob
Provides optimum rebound and compression performance for any given rider weight, personal ride preference, or personal riding style
Nitrogen gas bladder design allows ultra-fast response and stiction-free movement
Light to heavy riders can fine-tune ride preference
Aggressive to casual riding styles can tune to desired quality or personal preference
Made by hand in Sturgis, SD USA

Specifications10 specs

Extended Length: 13.00"
Color/Finish: Clear
Riding Style: Street
Reservoir Location: Piggyback
Units: Pair
Duty: Standard
Mounting Position: Rear
Shipping weight: 12.8 lb
Package size: 16.3 × 15.3 × 5.8 in
Country of origin: USA

Fitment14 models · Harley-Davidson

Harley-Davidson14 models

FXLR Low Rider Custom1987–1994
FXR Super Glide II1986–1994
FXR21999
FXR31999
FXR42000
FXRC Low Rider Chrome1985, 1987
FXRD Sport Glide Grand Touring1986
FXRDG Disc Glide1984
FXRS Low Glide1984–1988, 1991–1992
FXRS-Conv Low Rider Sport Convertible1990–1993
FXRS-SP Low Rider Sport1986–1993
FXRT Sport Glide1984–1992
Low Rider FXRS1989–1990, 1993
Sport Glide FXRT1993

Fitment comes from the distributor’s catalog. Double-check your year, model and trim before you order — or call the counter at 801-361-3010 and we’ll check it with you.

Part numbers

Salto part #: 1310-1946
Legend Suspension part #: 1310-1946

Shipping

In stock at a distributor warehouse. Ships in 2–4 business days by ground.

Ground shipping is $14.95, free on orders over $150. Stock is re-checked with the warehouse before your card is charged.

Questions4 answers

Is it in stock?: Yes — the distributor shows it on a shelf at a regional warehouse right now. We check again the moment you order, before anything is charged.
How fast will it get to me?: Usually 2–4 business days by ground.
Will it fit my machine?: The distributor lists it for the models in the Fitment section above. Not sure about your trim or year? Call the counter at 801-361-3010 and we’ll check it with you.
Is this genuine Legend Suspension?: Yes. It ships new from the same distributors the big online stores buy from — Legend Suspension part #1310-1946.
