Legend Suspension REVO ATS Adjustable Air-Assisted Coil Suspension System

• Legend’s patented design features an independently adjustable (front-to-rear) air-assisted coil suspension for hard-working utility UTV's
• Industry-exclusive, integrated helper air springs, offer a wide range of adjustability to improve ground clearance, chassis leveling, and reduce bottoming under heavy loads
• Designed to optimize ride quality and maintain the factory ride height of UTV's regardless of cargo, accessory, or attachment weights
• Custom coil spring rates improve ride quality when UTV is in an unloaded state
• Engineered to allow UTV's to be loaded to the OE manufacturer's GVWR without jeopardizing stability, safety, or comfort
• Aramid fiber-impregnated air springs provide high puncture resistance and unmatched durability
• Features heavy-duty 46 mm billet aluminum dampers with 16 mm hard chrome shafts for exceptional strength
• Easy access knob allows tool-free rebound adjustment for precise, fast, and repeatable adjustments for fine-tuning ride quality and performance across the entire damping profile
• Type III hard coat anodized for a long-lasting, durable finish
• Spherical bearings in mounting points eliminate suspension bind throughout the range of suspension travel
• Air pressure adjustments are easily made via a one-touch, wireless remote control and/or a Bluetooth mobile app
• Kit includes four shock assemblies, pre-mounted compressor assembly, remote control, wire harness, airline, and air fittings for easy installation
• Made in the USA
• Compatible with stock A-arms, not to be used with or as a lift kit.
• Not to be used with or as a lift kit.

Material

Aluminum

Mounting Position

Rear, Front

Type

Coilover Air

Color/Finish

Black, Anodized

Extended Length

19.0" Front / 23.0" Rear

Adjustment Type

Adjustable Air Spring

Units

Kit

Damping Method

Deflective Disc

Riding Style

UTV

Shipping weight

81.1 lb

Package size

28.5 × 17 × 29.5 in

Country of origin

USA

Salto part #

1310-2375

Legend Suspension part #

1310-2375
