Dynatek 2000-HDE PC-Programmable Digital Ignition Module

Dynatek · #2101-0043 · Starters & Ignition / Electrical & Gauges

A plug-in upgrade to the electronic advance ignition found on late model Harleys, these ignitions are micro-computer controlled, generating extremely accurate control over the entire ignition process
Allow riders to tailor the advance curve and rev limiter to the specific needs of their particular engine; four built-in advance curves cover the needs of stock to highly modified engines over a variety of operating conditions; four independent rev limiter choices from 6000 to 7500 rpm set the exact protection level needed
PC programmability allows you to define a wide-open and part-throttle curve, rev limits, dead-cranking revs and rear cylinder offset
A separate tach output wire allows clean tach operation during rev limiting and when in single-fire mode
A diagnostic LED indicator is included on the back of the control module to assist trouble shooting and static timing

$322.21

In stock. Ships in 2–4 business days · free shipping over $150.

Questions? Call the shop: 801-361-3010

Real shop · real humans · 1231 N 1300 W Ste A, Centerville, UT 84014

Description & features9 features

Comes with a 7-pin connector; can be used with either one ignition coil firing both cylinders (dual fire), or with two ignition coils, one firing each cylinder (single-fire); no other ignition offers this flexibility.

A plug-in upgrade to the electronic advance ignition found on late model Harleys, these ignitions are micro-computer controlled, generating extremely accurate control over the entire ignition process
Allow riders to tailor the advance curve and rev limiter to the specific needs of their particular engine; four built-in advance curves cover the needs of stock to highly modified engines over a variety of operating conditions; four independent rev limiter choices from 6000 to 7500 rpm set the exact protection level needed
PC programmability allows you to define a wide-open and part-throttle curve, rev limits, dead-cranking revs and rear cylinder offset
A separate tach output wire allows clean tach operation during rev limiting and when in single-fire mode
A diagnostic LED indicator is included on the back of the control module to assist trouble shooting and static timing
Made in the USA
IMPORTANT: On any electronic advance ignition such as the Dyna 2000-HD1 or the stock Harley ignition, you must use carbon fiber-type suppression spark plug wires to reduce radio frequency interference. Use of copper wires may cause malfunction of the ignition due to severe electrical noise generated at the spark plugs. The original wire supplied by Harley-Davidson should be okay.
Not for fuel-injected models.
HDE systems are not compatible with Dyna "S" systems. Use HD1/HD2 systems only.

Specifications12 specs

Model: Dyna 2000 Series
Color/Finish: Black
For Make: Harley-Davidson®
Ignition Type: Electronic
Type: Ignition
Units: Each
Ignition Fire Method: Dual, Single
Riding Style: Street
Features: 7 Pin
Shipping weight: 1.03 lb
Package size: 7.5 × 5.2 × 2.8 in
Country of origin: USA

Fitment33 models · Harley-Davidson

Harley-Davidson33 models

FLHR Road King1994
FLHS Electra Glide Sport1991–1993
FLHTC Electra Glide Classic1991–1994
FLHTCU Electra Glide Ultra Classic1991–1994
FLSTC Heritage Softail Classic1991–1995
FLSTF Fat Boy1991–1995
FLSTN Heritage Softail Nostalgia1993
FLSTN Heritage Softail Special1994–1995
FLTC Tour Glide Classic1991–1993
FLTCU Tour Glide Ultra Classic1991–1994
FXD Dyna Super Glide1995
FXDB-D Dyna Glide Daytona1992
FXDC Super Glide Custom1992
FXDL Dyna Low Rider1993–1995
FXDS-Conv Dyna Convertible1995, 1998
FXDWG Dyna Wide Glide1993–1995
FXLR Low Rider Custom1991–1994
FXR Super Glide II1991–1994
FXRS Low Glide1991–1992
FXRS-Conv Low Rider Sport Convertible1991–1993
FXRS-SP Low Rider Sport1991–1993
FXRT Sport Glide1991–1992
FXST Softail Standard1991–1993
FXSTC Softail Custom1991–1995
FXSTS Springer Softail1991–1995
FXSTSB Bad Boy1995
Low Rider FXRS1993
Sport Glide FXRT1993
Sportster 883 XLH1990–1993
Tour Glide Classic FLTC1994
XLH12001990–1993
XLH883DLX Sportster 883 Deluxe1990–1993
XLH883HUG Sportster 883 Hugger1990–1993

Fitment comes from the distributor’s catalog. Double-check your year, model and trim before you order — or call the counter at 801-361-3010 and we’ll check it with you.

Part numbers

Salto part #: 2101-0043
Dynatek part #: DD2000-HD1EP
UPC: 840094311039

Shipping

In stock at a distributor warehouse. Ships in 2–4 business days by ground.

Ground shipping is $14.95, free on orders over $150. Stock is re-checked with the warehouse before your card is charged.

Questions4 answers

Is it in stock?: Yes — the distributor shows it on a shelf at a regional warehouse right now. We check again the moment you order, before anything is charged.
How fast will it get to me?: Usually 2–4 business days by ground.
Will it fit my machine?: The distributor lists it for the models in the Fitment section above. Not sure about your trim or year? Call the counter at 801-361-3010 and we’ll check it with you.
Is this genuine Dynatek?: Yes. It ships new from the same distributors the big online stores buy from — Dynatek part #DD2000-HD1EP.
