Koso D2 LCD — Multifunction Meter

Fits models with traction control.

• High quality plug & play meter that is equipped with an 8-color changeable LCD display
• Designed to mount below cutout top handlebar clamp for a sleek look (handlebar riser kit with gauge cutout or gauge relocation kit may be required depending on application)
• Features a tachometer/speedometer combination with a programmable shift light and includes gear indicator
• Features vital reads such as engine temperature, battery voltage, tire pressure and a complete system of indicator lights to monitor vital signs on bike
• Plugs directly into the stock harness and works directly with CANBUS system
• Display range: 0-124 mph
• Effective temperature range: -4°F-185°F (-20°C-85°C)
• 12VDC battery voltage
• Measures 3-7/16” L x 1-1/16” W x 2-5/8” H
• XL models may require purchase of separate fuel level sensor kit (OEM PART #6120008) for fuel meter to function properly.

Model

D2

Units

Kit

Face Color

Black

Length

3-7/16"

Calibration

0 mph - 124 mph

Depth

2-5/8"

Type

Multi-Function Speedometer

Housing Color

Black

Width

1-1/16"

Riding Style

Street

Shipping weight

0.3 lb

Package size

5.6 × 5.4 × 3.3 in

Country of origin

Taiwan

Salto part #

2210-0607

Koso part #

BA080000

In stock at a distributor warehouse. Ships in 2–4 business days by ground.

Ground shipping is $14.95, free on orders over $150. Stock is re-checked with the warehouse before your card is charged.

Is it in stock?

Yes — the distributor shows it on a shelf at a regional warehouse right now. We check again the moment you order, before anything is charged.

How fast will it get to me?

Usually 2–4 business days by ground.

Will it fit my machine?

The distributor lists it for the models in the Fitment section above. Not sure about your trim or year? Call the counter at 801-361-3010 and we’ll check it with you.

Is this genuine Koso?

Yes. It ships new from the same distributors the big online stores buy from — Koso part #BA080000.
